Applicable Industries:
| Food |
Pharma And Healthcare |
Automotive |
Batteries & Fuel Cells |
Dairy |
Logistics |
Tobacco |
Technical Parameters:
| Model |
DR-ARGTJ |
| Type |
Double sprocket (CL) Single chain wheel |
| Power |
AC 220V/3ph、AC 380V/3ph |
| Output |
0.2、0.4、0.75、Gear motor |
| Structure material |
Al、CS、SUS |
| Roller tube |
1.5t、2.0tRoller*15t/20t |
| Sprocket |
Galvanized CS、SUS |
| Roller dia |
25、38、50、60 |
| Roller distance |
75、100、120、150 |
| Vaild roller width W2 |
300-1000（increase by 50） |
| Conveyor width W |
W2+136(SUS)、W2+140（CS、AL） |
| Conveyor length L |
>=1000 |
| Conveyor Height H |
>=200 |
| Speed |
<=30 |
| Load |
<=50 |
| Roller type |
CS、Plastic |
| Fuselage frame size |
120*40*2t |
| Travel directin |
R、L |
Feature:
1、200-1000mm conveyor width.
2、Adjustable conveyor height and speed.
3、Our wide selection of sizes lets you build your conveyor line to your exact needs and offers expansion capability for future growth.
4、Cartons follow the twists and turns of the conveyor path without using engineered curves
5、we can provide good after-sale service.
6、every product can be customized
Detail:
